Hatec S-12
Specification of Hatec S-12
For reducing direct sun radiation intruding glass surfaces. The no-handling and no-maintenance system stands off heat however insures almost obstacle-free visibility.
The louvre boards and the supports are rust-free AlMgSi 0,5 aluminium profiles.
The consoles serving as the support structure are made of hot dip galvanized ST 37 steel. The material of the fixing elements is V4A/V2A stainless steel. For avoiding noise caused by the wind and dilatation emerging as an effect of the heat the Hatec sunshade louvre boards are connected to the support profiles with RAL7035-colour plastic support elements. Each louvre board can be dismantled non-destructively.
Placement:
Horizontally
Above extension of 2.3 m support on the top or at the bottom
Mounting with consoles gliding into one another
Internal corners, external corners
The louvre boards are located either above or under the support elements
Louvre board angle: 30° top-mounted
Technical specification:
Elongation :
Full length :
Span of supports :
Distance betweeb louvre board s :
Louvre board width :
Louvre board thickness :
Louvre board design :
Support :
Louvre board support :
Surface treatment:
Raw aluminium (untreated) :
Natural anodized aluminium :
Powder coated, in RAL colours :
Hatec S-12
Technical specification:
Louvre board thickness :
Louvre board width :
Louvre board length :
Anodic oxidation :
Powder coating :
Support :
Span of supports :
Support structure :
Fixing material :
Heat insulation of the support structure :
Tilt angle of louvre board s :
Louvre board support :
Maintenance :
